Agricultural Gearbox

Product Name：

Agricultural Gearbox

Material：

A356-T6  A360.0 A355,A319,A413,ALSI7MG,AlSi12,AlSi5Cu,AlSi6Cu4 Alsi10mg Casting Manufacturing: aluminium  casting gear housing Weight: 8.00 kg

CNC Machining: Available

Surface Treatment: Painting, Anodizing 、power coating，or As Per Request OEM & ODM Services: Available

Development process

We can produce aluminium casting gear housing 609 to customer requirements, after receiving customer samples or drawings, first evaluate the production process of the product, and carefully calculate the cost of the product, under the premise of ensuring quality, select the manufacturing process at the lowest cost. After the manufacturing process is determined, the parts that need to open the mold need to be developed in the premise, because the opening time will generally be between 30-60 days, so as not to delay the delivery time. Product engineers who need to manufacture different processes will plan and decompose 3D,2D drawings according to requirements, and formulate SOPs, while carrying out quality control, testing and inspection tool design planning work, APQP PPAP FMEA and other control plans, to ensure quality under the premise of delivery to customers on time. After the customer confirms that the product meets the requirements, it will be mass-produced.

What is aluminium alloy casting?

The casting alloy melted by adding a certain amount of other metal or non-metallic elements to pure aluminum is called a cast aluminum alloy. Cast aluminum alloy is divided into five categories: aluminum silicon (AI-si) class, aluminum copper (AI-Cu), aluminum magnesium (AI-Mg), aluminum zinc (AI-Zn) class, the use of mold modeling to form a sand internal cavity shape, the aluminum alloy through the heating method temperature control 700-740 degrees, injected into the sand type, the temperature is too high easy to burn the magnesium components inside the alloy, the temperature is too high will also make the alloy increase the amount of suction, the product is easy to produce pinholes and porosity, control the casting temperature, Casting time can improve the quality of the casting. The control of the cooling time is also a way to improve the quality of the casting. Castings can be heat treated to increase the strength of aluminum alloy materials

What kind of aluminium alloy we can do?

A356-T6  A360.0 A355,A319,A413,ALSI7MG,AlSi12,AlSi5Cu,AlSi6Cu4,Alsi10mg

What Further Processes We Can Make After Raw Castings:

Deburring & Cleaning Shot Blasting / Sand Peening Heat Treatment: Quench, Tempering Surface Treatment: Painting, Anodizing 、power coating，or As Per Request CNC Machining: Turning, Milling, Lathing, Drilling, Honing, Grinding,
